China GW-12 Outdoor AC HV Disconnect Switch Manufacturer, Supplier, Factory

XUCKY Electric is a leading China manufacturer and exporter specializing in JDZX10 Type Voltage Transformer. Voltage transformers are much like small power transformers, differing only in details of design that control ratio accuracy over the specified range of output. Current transformers have their primary windings connected in series with the power circuit, and so also in series with the system impedance.

JN22-40.5 Series High Voltage Earthing Switch is an advanced level product with high tech parameters performance. After comprehensive evaluation, it conforms to GB1985 AC HV disconnect switch and earthing switch, applies to power system of 40.5kV and AC 50Hz. Can be used with KYN61-40.5 and other types high voltage switchgear, also play a protective role in the high-voltage electrical equipment overhaul.

XUCKY NDM1 Moulded Case Circuit Breaker (NDM1, hereinafter referred to as MCCB), is new circuit breakers which have been designed and developed by the company using international advanced technology. The circuit breakers are of the following characteristics: compact size, high breaking capacity, short arc-over distance and shakeproof, is ideal products applied on land or ships. The rated insulation voltage of the circuit breaker is 800V (500V for NDM1-63), it is suitable for the distribution network of AC 50Hz / 60Hz, rated working voltage of 690V and rated current of 1250A, to distribute power and protect circuit and power equipment from being damaged caused by overload , short-circuit, under-voltage and other fault. Also for protection infrequent conversion of the circuits and infrequent start of motor and overload, short circuit, under voltage.

China XUCKY Electric customized FZRN61 Load Break Switch with Disconnect Switch and Earth Switches are three-phase high voltage switch equipment with rated voltage of 12KV and rated frequency of 50Hz, are used to switch load currents, closed loop current, no-load transformer and cable charging current, and make short circuit current. The three-position miniaturized vacuum load break switch equipped with an disconnect switch at the top and a earth switch at the bottom can withstand short-circuit current.

ZW32-12 outdoor vacuum circuit breaker (hereinafter referred to as "vacuum circuit breaker") is a three-phase AC 50Hz outdoor high voltage switch equipment, mainly used in the 10KV outdoor distribution system of the rural and urban network as the open or close load current, the overload current and the short circuit current, and can also be used in other similar places. ZW32-12 outdoor vacuum circuit breaker meet the national GB 1984-2003, IEC62271-100 "AC high voltage circuit breaker" and GB/T11022-1999 "Common technical requirements for high voltage switchgear and control equipment standards".

XUCKY Electric is a leading China manufacturer and exporter specializing in VSG-12 Series Indoor High Voltage Vacuum Circuit Breaker. We have a wide range of products to meet the different needs of our customers worldwide. Our commitment to superior quality, innovative technology and excellent customer service makes us stand out in our industry.
